Modified PTFE Sheet
Color: Brown
Filler: Silica
Summary: Specialized in acids media.
For chemical and pharmaceutical industry seal gasket.
Moderate concentrations of acids and some caustics, hydrocarbons, solvents, water, refrigerants, and cryogenics.
Excellent performance in gaseous media.
Excellent resistance against most chemicals.
Outstanding recovery.
Reduced cold flow and creep.
Low assembly pressure.
-
Supply standard
Sheet Size: 1500*1500
Gasket size: ASME B16.21 / EN 1514-1
Thickness: 1.0mm 1.5mm 2.0mm 3.0mm
PH: 0 ~ 14.
Use temperature: -100 ℃ ~ + 250 ℃
| Item | Standard | Data |
| Compressibility 350bar % | ASTM F36A-99 | ≥10 |
| Recovery 350bar % | ASTM F36A-99 | ≥30 |
| Tensile Mpa | ASTM 152-95 | ≥12 |
| Specific Gravity g/cm3 | ASTM D 792 | 2.2 |
| Seal leakage rate(cm3/s) | GB/T9129-2003 | < 1x10-3 |
| ASTM test reference to gasket thickness 2 mm; DIN test reference to gasket thickness 1.5 mm. | ||
